Adjuster (2), located on the lever, allows a maximum
adjustment (Q) of 11 mm (0.4 in), whereas the
standard adjustment (starting one) is of 5 mm (0.2 in).
If working such adjuster proves insufficient, work the
secondary adjuster (3) on vehicle RH side.
Warning
In case of a slipping clutch due to clutch wear,
adjuster (2) on the lever must NEVER be loosened,
but screwed, as described above.
If the clutch is still slipping, go to a Dealer or a Ducati
authorised service centre.
Fig. 135
Fig. 136
198
