PIPING LEGEND
ZONE VALVE
BALL VALVE
AIR SEPERATOR
CIRCULATOR
DRAIN
COMBINATION FILL

BYPASS VALVE
DIVERTER VALVE
T&P OR RELIEF VALVE
THERMOSTATIC MIXING VALVE


10K Ω 
TEMPERATURE & PRESSURE GAUGE

FLAT PLATE HEAT EXCHANGER
(COMBI ONLY)
STRAINER
PIPING LEGEND
PURGE VALVE
MAGNETIC DIRT SEPARATOR
