Duplo DC-545 HC - Chapter 1 Operating Instraction - DC545 HC; Part Names and Their Functions

12
e
r
q
w
t
No. Name Function
q Level adjustment lever For adjusting the level of the elevator 6
w Separator adjustment knob For adjusting the amount of space between sheets of paper 6
e Airflow adjustment knob For adjusting the amount of airflow 7
r Skew adjustment knob For adjusting the skew of the paper 7
t Stoppers For holding the rear edge of the paper stack 5
Reference
Page
Operating Instraction - DC545 HC
Chapter 1
Part names and their functions
