Before Using This Machine - DC545 HCEX
2
How to Set up the System
This section describes the cautions and the procedure when you set up this machine.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Take out the machine from the package and place the machine on a flat and stable
table.
WARNING
• Do not try to lift the machine by yourself. Two or more people are required to prevent
injury and/or damage to the machine.
• When you open the box, be sure not to injure yourself or others with a cutter or the like.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Detach the shipping bracket.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Attach the feed tray to the main body.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Attach the paper tray to the main body.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Continue Page •••
