Appendix - DC545 HC/DC545 HCEX
This chapter lists the specifications and an index.
Specifications
Product name / Model No. DC-545 with HC AUTO FEEDER
Input paper size Desktop model
Paper size Min.:8.5" x 11" / A4
Max.:12.6" x 18" / A3
Input paper weight Min.:110gsm
Max.:230gsm <No curl in the paper>
Finishing size Min.:2"(Width) x 3.5"(Length) <Business card size>
Lead edge trim Min.:0.125"(3.2mm)
Trail Edge Trim Min.:0.125"(3.2mm)
Side edge trim Min.:0.125'(3.2mm)
Max.:4.5"(114mm)
Speed Max : 9ppm (A4 lengthwise. 4-side trim. 1 score)
Trim/Score tolerance +/- 0.03"(+/- 0.762mm) <With paper cutting length not exceeding 18">
Media type Range: Regular copy paper to coated heavy weight paper
Feeding method Automatic Feeding (Air suction method)
Feed tray capacity 100mm
Stacker Drop type
Power supply
AC120V +/- 10% , 50/60Hz, 1.0A
AC230V +/- 10% , 50/60Hz, 0.6A*
Machine dimensions(mm) 1370(W) x 580(D) x 960(H)
Machine weight(kg) 109.6 (Main body 56.4 , Feeder 20.4 , Stand 32.8)
1.Four scores perpendicular to the feed direction.
Other Features
2. Up to 5 cuts parallel to the feed direction. (2 x margin slitters and 3 x center slitters.)
3.Up to ten cuts perpendicular to the feed direction.
4.Automatic setting of slit, cut and score position.
DC-545 with HC AUTO FEEDER Specifications
