Troubleshooting - DC545 HCEX
When a Paper Jam Has Occurred
Procedure of Removing Front and Rear Creaser Guides
This operation also needs to be done when the creaser or the cutters are locked.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Please open the Front/Rear Cover of DC-545HC.
Front Cover Rear over
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Loosen the 2 set-screws on both sides of Front/Rear Creaser Guides, counter clockwise
2 or 3 times. Use the Hex Driver contained in the kit.
IMPORTANT
The cap bolt may fall off if it is loosened more than necessary.
