46
When a Paper Jam Has Occurred
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Please slide the guide toward
qq
qq
q (non-operator side) then pull up toward
ww
ww
w.
Front Creaser Guide Rear Creaser Guide
IMPORTANT
The figures of Front and Rear Creaser Guide are similar.
When installing Creaser Guide, please refer to the following figure.
Rear Guide
Front Guide
Docu Cutter(HCEX) 4_30-52 03.12.8, 3:10 PM46
To Next Page
