56
AUTO CUT
If there is no waste on the sheet, be sure to turn the AUTO CUT feature OFF. See Examples 1 and 2 below.
Definition of Programming Terms
AUTO CUT is turned ON and OFF in the operator menu and is a global function, i.e. it is not saved specific to a job.
Jobs requiring AUTO CUT ON and OFF CANNOT mixed in the feed tray.
PLEASE NOTE: When the total number of scores and cuts (including those cuts due to AUTO CUT) exceeds 17 the
following message appears on LCD display:
––– E 6 –––
DATA ERROR
If a E6 data error occurs the job must be re-designed or reprogrammed so the total number of cuts and creases do not
exceed 17
Example 1 - When AUTO CUT must be OFF
Example 2 - When AUTO CUT must be OFF
Docu Cutter(HCEX) 5_53-69 03.12.8, 3:11 PM56
