Duplo DC-545 HC - Page 63

62
Job Type
MARK 1
MARK 2
LEFT SL
RGHT SL
C.L. SL
C.R. SL
OP1 SL
OP2 SL
CUT1
CUT2
CUT3
CUT4
CUT5
CUT6
CUT7
CUT8
CUT9
CUT10
SCR. 1
SCR. 2
SCR. 3
SCR. 4
TOTAL LENGTH
Pan8 × 10
1up Lg
Card
2up
Scrapbook
2up
Postcard
11up
Business
Card
4up
Business
Postcard
Large
Brochure
PROGRAM
NUMBER
#9 #10 #11 #12 #13 #14 #15 #16
47 47 47 47 47 47 47 47
9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2
6.4 12.7 13.5 6.4 31.8 6.4 6.4 9.5
209.6 203.2 202.4 272.9 0 209.6 209.6 269.9
0 101.6 0 136.4 0 57.2 108.0 0
0 0 0 0 184.2 158.8 0 0
0 114.3 0 142.9 0 108.0 0 0
17.1 19.1 12.7 12.7 28.6 6.4 12.7 16.9
271.1 266.7 266.7 419.1 130.2 95.3 139.7 415.9
0 0 0 0 149.2 184.2 266.7 0
0 0 0 0 250.8 273.1 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 139.2 215.4 0 0 0 215.9
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
279.4 279.4 279.4 431.8 279.4 279.4 279.4 431.8
NOTES
THESE VALUES ARE CURRENT AS OF OCTOBER 2002
ALL DIMENSIONS ARE IN MILLIMETERS
8.5 X 11 inches = 215.9 X 279.4 millimeters
11 X 17 inches = 279.4 X 431.8 millimeters
Factory Preset Jobs
Docu Cutter(HCEX) 5_53-69 03.12.8, 3:11 PM62
