Attach the
crease tool (male)
removed in step 4.
2
101
When a Document Jam Has Occurred
4
Troubleshooting
Loosen the two fi xing screws on the cutter section
cover.
Remove the jammed document with tweezers or
pliers.
Attach the
upper plate assy
removed in step 3 and
tighten the four fi xing screws loosened to secure it.
Attach the
cutter section cover
removed in step 5
and step 6, and tighten the two fi xing screws.
Slide the cutter section cover toward the
non-operator’s side and then remove it upward.
Close the
top cover
.
Top cover
