Duplo ULTRA 200PRO User Manual

44
3. Call for service
E008
S8 E-Stop 2 Error
1. Reset Emergency Stop Switch
2. Emergency Stop has malfunctioned
3. Call for service
E009 S9 Oil Pan Sensor Error 1. Put Oil Pan in coating position
2. Sensor has malfunctioned
3. Call for service
E010
S10 Flow Sensor / Oil Empty
1. UV bucket is empty
2. Flow Sensor has malfunctioned
3. Pump hose not in position
4. Call for service
E011 S11 IR Not Lit 1. Heater Element has malfunctioned
2. Fuse had blown
3. Call for service
E012
S12 IR Thermostat
1. Thermostat has malfunctioned
2. Call for service
E013
S13 Input Sensor Error
Auto gap sensor see it and sheet not get into Input
sensor means paper wrap around applicator
E014
S14 UV Lamp Thermostat 1. Suction Motor malfunction
2. Thermostat has malfunctioned
3. Call for service
E015 UV Lamp Not Lit 1. UV Lamp is not cool
2. UV Lamp has malfunctioned
3. Call for service
E016
UV Oil Valve Error
Coating valve is OFF or Cleaning valve is ON when
doing coating
E017
Cleaning Valve Error
Cleaning valve is OFF and Coating valve is ON when
doing cleaning
E018
Index Sensor Error
1. Call for service
E019
Auto Gap Sensor Error
1. Call for service
“□□□□”
UV Lamp 900 Hours Warning UV lamp reaches to 900 hours
E022
Coater Motor Stall 1. Paper jam wrap around metering roller
2. Belt Broken
3. Driver goes bad
Control Panel No
Function
1. Interface cable loose
2. Driver Burn
Call for service
No Display
5V off
Call for service
Not Curing
1. Reflector dirty
2. Lamp aging
3. UV power is not enough
1. Slow down the coating speed, check the reflector
protection film is removed
2. Call for service
Smearing
1. Scraper blade dirty
2. impression roller dirty
1. Clean scraper blade
2. Clean impression roller
