Seam-end pattern
This parameter selects the form of the seam pattern at the seam end.
Straight seam pattern
Slanting seam pattern (left)
Slanting seam pattern (right)
–
Select the required seam form with cursor keys “ï”or “ð”.
–
Press the “OK” key.
The seam-angle entry window appears:
Seam angle
Entry: 01 ... 13 [mm]
NB:
The seam-angle entry is checked.
If the fixed sewing length and the values entered
cannot be sewn on the machine, an
automatic adjustment of the seam angle
is carried out for the seam end.
Sewing-length measurement
Three different possibilities can be selected.
Distance measurement, automatic recognition by light barrier and
automatic recognition of the flap angle.
An interlock system prevents more than one possibility from being
selected. The other are blocked.
Distance measurement
In distance measurement the sewing length is
displayed on the main screen.
Automatic recognition of flap beginning and flap end
In this setting the reflecting light barrier for the
recognition of the flap beginning and flap end is switched
on for sewing with flaps.
Maximum flap length
Entry: 020 ... 180 [mm] optional 220 mm
Automatic flap-angle recognition
Sewing with two light barriers for automatic
flap-angle recognition.
Maximum flap length
Entry: 020 ... 180 [mm] optional 220 mm
Stitch length
Entry: 2.0 ... 3.0 [mm]
19
