Dwin T5L ASIC Series User Manual

T5L_ASIC Development Guide
- 11
-
www.dwin-global.com
D WI N T echnology
Pro f essional , Credi t able , Success f ul
2.3 Basic Performance Parameters
Parameter
Unit
Minimum
Typical value
Maximum
Instructions
CPU core voltage
V
1.10
1.20
1.30
T5L2
V
1.20
1.25
1.35
T5L1
CPU core current
mA
100
Dual-core 200MHz full speed
operation
IO voltage (VIO)
V
1.8
3.3
3.6
5V TTL/CMOS level input
requires voltage division or
clamp protection
AD operating voltage(VADD)
V
1.8
3.3
3.6
AD reference voltage (Vref)
V
VADD+0.3
AD input voltage
V
Vref+0.3
IO high level output
amplitude(VOH)
V
3.0
VIO=3.3V,IO load current 8mA
IO low level 1utput
amplitude(Vol)
V
0.3
VIO=3.3V,IO load current 8mA
IO high level output current
mA
-10
VIO=3.3V, VOH=3V
IO low level output current
mA
10
VIO=3.3V, VOL=0.3V
IO port turnover speed
MHz
100
IO high level recognition
voltage(VIH)
V
1.6
IO low level recognition
voltage(VIL)
V
0.6
External crystal frequency
MHz
10.0
11.0592
12.0
CPU main frequency (CPU_CLK)
MHz
206.4384
Corresponding to 11.0592MHz
crystal, CPU main frequency =
crystal frequency* 56/3.
350MHz version code can be
customized.
Working temperature
℃
-40
+85
Storage temperature
℃
-55
+105
ESD protection capability
KV
2
HBM
