Dwin T5L ASIC Series User Manual

T5L_ASIC Development Guide
- 6 -
www.dwin-global.com
D WI N T echnology
Pro f essional , Credi t able , Success f ul
OS
5
P1.0
I/O port
OS
6
P1.1
I/O port
OS
7
P1.2
I/O port
OS
8
P1.3
I/O port
OS
9
P1.4
I/O port
OS
10
P1.5
I/O port
OS
11
P1.6
I/O port
OS
12
P1.7
I/O port
OS
13
VDD
T5L1=1.25V
T5L2=1.2V
OS
14
VIO
3.3V
OS
15
P2.0
I/O port
OS
16
P2.1
I/O port
OS
17
P2.2
I/O port
OS
18
P2.3
I/O port
OS
19
P2.4
I/O port
OS
20
P2.5
I/O port
OS
21
P2.6
I/O port
OS
22
P2.7
I/O port
OS
23
VDD
T5L1=1.25V
T5L2=1.2V
OS
24
VIO
3.3V
OS
25
P3.0
I/O port
EX0
External interrupt 0 input
OS
26
P3.1
I/O port
EX1
External interrupt 1 input
OS
27
P3.2
I/O port
OS
28
P3.3
I/O port
29
GND
30
GND
31
GND
32
OS/GUI
0:GUI JMARK,
1=OS JMARK
33
/RST
System reset
input
34
JMARKS
PIN35#-PIN38# Select: 0=JMARK, 1=I/O port
GUI
35
P0.0
I/O port
TMS
JMARK interface
TCON_CS
LCD screen
TCON interface
GUI
36
P0.1
I/O port
TCK
JMARK interface
TCON_CLK
LCD screen
TCON interface
GUI
37
P0.2
I/O port
TDI
JMARK interface
TCON_DATA
LCD screen
TCON interface
GUI
38
P0.3
I/O port
TDO
JMARK interface
TCON_RST
LCD screen TCON
interface
GUI
39
P0.4
I/O port
TX1
UART1 data sending
GUI
40
P0.5
I/O port
RX1
UART1 data receiving
GUI
41
P0.6
I/O port
FSK_TX
FSK transceiver data sending
