Dymax BlueWave® 200 Version 3.0 User Guide
Sample Wiring Diagram
Figure 34. Sample Wiring Diagram
24VDC POWER
SUPPLY
BLUEWAVE® 200 PLC INTERFACE
+24VDC
+24VDC RETURN
2000 Ω
USE ONLY THE
SIGNALS
REQUIRED BY
THE PLC
PROGRAM
FROM PLC
10000 Ω
TO PLC
3
4
5
6
7
8
9
10
11
12
13
14
15
Connector Pin Out
The PLC Connector pin numbers are shown in Figure 35 below.
Figure 35. Connector Pin Out
1
2
