Text size and style apply to the currently selected text. If no text is selected, the
size and style apply to all the text in the text box.
Laminated cable wrap labels can only be printed using pre-sized Laminated Wire/
Cable Wrap label cartridges.
Use serialization to automatically create a series of labels. See Creating a Series
of Labels on page 35.
Laminated cable wrap label properties are based on the label cartridge selected
and cannot be changed.
To create a laminated cable wrap label
1 From the Home screen, tap Laminated Cable Wrap.
The editor displays a new blank label based on the label cartridge inserted. If
no label cartridge is inserted, you are asked to select a label cartridge.
2 Add text and formatting.
Cable Wrap Label
The cable wrap label is one of several cable management specific labels. The
content of the cable wrap label is repeated three times vertically so that it can be
viewed from any angle when the label is wrapped around the cable.
One text box is automatically added to the label. Additional text box, barcode,
image, and shape objects cannot be added to a cable wrap label.
Text size and style apply to the text on the label.
Use serialization to automatically create a series of labels. See Creating a Series
of Labels on page 35.
Cable wrap labels can be printed on any type of continuous labels.
The label properties you can set are:
To create a cable wrap label
1 From the Home screen, tap Cable Wrap.
2 Do one of the following:
• Select the cable type.
•Tap Custom and then select the cable diameter.
3 Follow the steps to configure your label.
4 Add text and formatting.
Heat-Shrink Tube Label
The heat-shrink tube label is one of several cable management specific labels.
Heat-shrink tube labels can be printed on any continuous or pre-sized Heat-Shrink
Tube labels.
Cable type and
diameter
Cable type: CAT 5/6, COAX, AWG: 4/0 - 2/0, AWG: 0 - 2, AWG: 3 - 5,
AWG: 6+, or Custom
Diameter - Available when Custom is selected for Cable type.
Minimum: 5/32” (4 mm)
Maximum: 2” (50.8 mm)
