4 Add formatting as desired.
Vertical Breaker Label
The vertical breaker label is one of two types of labels for use on a breaker box.
See Horizontal Breaker Label on page 20.
One text object is automatically added for each breaker. Additional text box,
barcode, image, and shape objects cannot be added to vertical breaker labels.
Text size and style apply to all breakers on the label and all labels in the file. When
Auto fit text is selected for font size, the text is automatically resized to fit that
breaker. So you may see differences in text size for each breaker.
Use serialization to automatically populate the breakers. When all the breakers are
filled on the current label, a new label is created. See Creating a Series of Labels
on page 35.
Vertical breaker labels can be printed on any type of continuous labels.
The label properties you can set are:
To create a vertical breaker label
1 From the Home screen, tap Vertical Breaker.
2 Follow the steps to configure your label.
3 Add text for each breaker.
4 Add formatting as desired.
Terminal Block Label
Terminal block labels are created by specifying the orientation (portrait or
landscape), the number of blocks, and the block height.
One text object is automatically added for each block. Additional text box,
barcode, image, and shape objects cannot be added to terminal block labels.
Text size and style apply to all blocks on the label and all labels in the file. When
Auto fit text is selected for font size, the text is automatically resized to fit that
block. So you may see differences in text size for each block.
Use serialization to automatically populate the blocks. When all the blocks are filled
on the current label, a new label is created. See Creating a Series of Labels on
page 35.
Terminal block labels can be printed on any type of continuous labels.
Breaker
dimensions
Number of breakers - Maximum: 99 breakers
Breaker height - Minimum: 1/4” (6.35 mm); Maximum: 5” (126.9 mm)
Breaker poles Number of poles for each breaker. Maximum: 3
Label outline Yes - Show label outline.
No - Hide label outline. (Default)
Separator lines Yes - Print a separator line between each breaker. (Default)
No - Don’t print a separator line between each breaker.
Leader/trailer
match
Yes - Blank space is equal at the beginning and end of the label. (Default)
No - No blank space is added at the end of the label.
