42
XTL
™
500
User Guide
Collated
A101 A102 A103 A101 A102 A103 A101 A102 A103
Not collated
A101 A101 A101 A102 A102 A102 A103 A103 A103
This setting is saved with your label file.
To turn off collation
1 Press and hold to display the print options menu.
2 Select Collate and then select No.
3 Tap Done and then press .
Mirror
The mirror option allows you to print the contents of your label
backwards, from right to left, as you would see the contents of
your label in a mirror.
This setting is not saved with your label file.
To print from right to left
1 Press and hold to display the print options menu.
2 Select Mirror and then select Mirror content.
3 Tap Done and then press .
Cut Labels
When printing multiple copies, the label maker cuts each label as it prints.
You can change this setting so that the label maker prints all labels continuously
and automatically cuts once after printing is complete. A label separator cut mark
is printed between each label to show where each label should be manually cut.
To choose when to cut multiple labels
1 Press and hold to display the print options menu.
2 Select Cut labels.
3 Select one of the following:
• All labels
•Each label (default)
4 Tap Done and then press .
Since the XTL
™
500 label maker does not have a manual cutter, the Print options
screen contains a Cut label button at the bottom of the screen that you can use
to cut a label manually at any time. This feature can be useful to cut unwanted
label material at the beginning of a new label cartridge.
Feed
You may need to feed additional label material before you cut a label or feed a
label that does not advance from the label exit slot properly.
To feed the label
1 Press and hold to display the print options menu.
