9.4 DATA ACQUISITION
Table 6: Ethernet IP/Serial Data Acquisition
Item #1
Drive Speed in %
0 to 10000
Item #2
Drive Speed In RPM
0 to Max RPM
Item #3
Reference
0 to 10000
Item #4
Set Point
0 to 10000
Item #5
Motor Amps (XFMR)
0 to 250
Item #6
Clutch Amps (LEM)
0 to 250
Item #7
Brake Amps (LEM)
0 to 250
Item #8
Analog Input Pot or 4-20 mA
0 to 250
Item #9
Drive Status “tb_in_a”
16 bit
Jog; PLC RUN; PRESET 1/2; Auto/Man; E-Stop
Item #10
Drive Status “key_in_a”
16 bit
Keypad Button Status
Item #11
Drive Status “db_in_a”
16 bit
Program Status; Source Selects; etc.
Item #12
Drive Status “db_in_b”
16 bit
Faults; Presets; Status
Item #13
Drive Status “state_a”
16 bit
Drive State On Off; Local / Remote; Etc.
Item #14
Drive Status “state_b
16 bit
Drive Commands: Stop Run Jog Fault, etc.
Item #15
Drive Status “state_c”
16 bit
Keypad Run & Stop Presets; Pot.
Item #16
Drive Status “misc_in_a”
16 bit
Fault Listing
Item #17
Software Version
5 byte
