4 CA 150 M150EN2
TECHNICAL SPECIFICATIONS
Weight and sizes CA150 CA150D CA150PD CA150P
Operating mass with ROPS, EN500, kg (lbs) 6930 (15,300) 7130 (15,700) 7430 (16,400) 7230 (16,000)
Operating mass without ROPS, kg (lbs) . 6600 (14,600) 6800 (15,000) 7100 (15,700) 6900 (15,200)
Operating mass with cab, kg (lbs) ........... 7150 (15,800) 7350 (16,200) 7650 (16,900) 7450 (16,400)
Length, standard-equipped roller, mm (in) 4776 (188) 4776 (188) 4871 (192) 4871 (192)
Width, standard-equipped roller, mm (in) . 1852 (73) 1852 (73) 1852 (73) 1852 (73)
Height, with ROPS, mm (in) .................. 2784 (110) 2784 (110) 2825 (111) 2825 (111)
Height, with silencer, mm (in) ................ 2525 (99) 2525 (99) 2540 (100) 2540 (100)
Height, with cab, mm (in) ....................... 2815 (111) 2815 (111) 2857 (112) 2857 (112)
Fluid volumes (Liters) (gal or qts)
Rear axle:
• Differential ................................................. 7,0 (7.4 qts)
• Planetary gearing ...................................... 0,8/side (0.8 qts) /each side
Drum oil ....................................................... 10,5 (11.1 qts)
Hydraulic reservoir ...................................... 52 (13.7 gal)
Fluid in hydraulic system (D, PD) ............... 18,0 (4.8 gal)
Lubricating oil, Diesel engine ....................... 8,0 (8.5) qts)
Coolant, Diesel engine ................................ 12,5 (13.2 qts)
Fuel tank ..................................................... 225 (59.4 gal)
Electrical system
Battery ......................................................... 12 V, 170 Ah
Alternator ..................................................... 14 V, 60A
Fuses .......................................................... See under main heading: Electrical system
Tires
Tire size ...................................................... 420/70 B24 (Std type) 14,9-24T461 8 ply (Tractor type)
Air pressure ................................................ 110 kPa (1,1 kp/cm
2
) (16 psi)
As extra equipment, the tires can be filled with liquid (extra weight up to 350 kg/tire)
(770 lbs/tire). Remember this extra weight when you perform service.
Compaction data CA150 CA150D CA150PD/P
Static linear load ......................... kg/cm (pli) 21,2 (118.7) 21,7 (121.5) –
Amplitude (High).............................. mm (in) 1,7 (0.067) 1,7 (0.067) 1,7 (0.067)
Amplitude (Low) .............................. mm (in) 0,8 (0.031) 0,8 (0.031) 0,8 (0.031)
Frequency (High amplitude) ......... Hz (vpm) 29 (1740) 29 (1740) 29 (1740)
Frequency (Low amplitude) .......... Hz (vpm) 40 (2400) 40 (2400) 40 (2400)
Centrifugal force (High amplitude) .... kN (lb) 100 (22,500) 100 (22,500) 124 (27,900)
Centrifugal force (Low amplitude)..... kN (lb) 94 (21,150) 94 (21,150) 118 (26,550)
WARNING
