FINAL QUALITY CHECK (QC) CHECKOFF SHEET
DYNATRON SOLARIS
®
PLUS SERIES | SERVICE MANUAL REV. 6 | AUGUST 29, 2017 149
Device Specific Procedure
QC, Assembly, Calibration, and Test
D719 Check Sheet -
3 of 9- DS0408A – REV 1
DYNATRON SOLARIS
PLUS
ULTRASOUND
FINAL QUALITY CHECK (QC)CHECK SHEET
Head SN: 5cm______________________10cm______________________2cm_______________________
(initials or mark)
Refer to Test equipment operation manual and unit operating instructions/ manuals
REPAIR/RS
PROD
1
Verify head temp.
2
Verify coupling.
3
Verify soundhead serial number
4
Combo with stim: Verify stim output through soundhead, using combo cable
5
Verify ultrasound output power
5cm
2.5 Watts (0.5)
5 Watts (1.0)
10 Watts (2.0)
1,2,3 MHz
2.4 – 2.6
4.9 – 5.1
9.8 – 10.2
10cm
5 Watts (0.5)
10 Watts (1.0)
20 Watts (2.0)
1,2 MHz
4.9 – 5.1
9.8 – 10.2
18.0 – 20.4
3 MHz
4.9 – 5.1
9.8 – 10.2
2cm
1 Watt (0.5)
2 Watts (1.0)
4 Watts (2.0)
1,2,3 MHz
0.9 – 1.1
1.9 – 2.1
3.5 – 4.1
Repair/RS: Record Parameters Before Calibration
2cm
1 mHz
2 mHz
3 mHz
5cm
1 mHz
2 mHz
3 mHz
10cm
1 mHz
2 mHz
3 mHz
Freq
Freq
Freq
Imped
Imped
Imped
Production & Repair/RS: Parameters Durring Calibration
2cm
1 mHz
2 mHz
3 mHz
5cm
1 mHz
2 mHz
3 mHz
10cm
1 mHz
2 mHz
3 mHz
Freq
Freq
Freq
Imped
Imped
Imped
Volts
Volts
Volts
Repair/RS: Output as Recieved Calibrated Output
5cm
2.5W (0.5)
5Watts (1.0)
10W (2.0)
5cm
2.5W (0.5)
5Watts (1.0)
10W (2.0)
1 MHz
1 MHz
2 MHz
2 MHz
3 MHz
3 MHz
10cm
5W (0.5)
10Watts (1.0)
20W (2.0)
10cm
5W (0.5)
10Watts (1.0)
20W (2.0)
1 MHz
1 MHz
2 MHz
2 MHz
3 MHz
3 MHz
2cm
1W (0.5)
2W (1.0)
4W (2.0)
2cm
1W (0.5)
2W (1.0)
4W (2.0)
1 MHz
1 MHz
2 MHz
2 MHz
3 MHz
3 MHz
ACCEPTANCE:
Initials:
Date:
