FINAL QUALITY CHECK (QC) CHECKOFF SHEET
DYNATRON SOLARIS
®
PLUS SERIES | SERVICE MANUAL REV. 6 | AUGUST 29, 2017 148
Device Specific Procedure
QC, Assembly, Calibration, and Test
D719 Check Sheet -
2 of 9- DS0408A – REV 1
Refer to Test equipment operation manual and unit operating instructions/ manuals
REPAIR/RS
PROD
9
TRI-WAVE LIGHT MEZZANINE OUTPUT:
a) Verify treatment selections work
b) Verify light pad operation
c) Verify light probe operation
Refer to Table for probe and pad treatment times
Wave length
Combination
DCP3
6 Joules
DLP3
10 Joules
IR / Red / Blue
1:00 min
8:42 min
10
Labels:
a) Apply Serial Number Label
Earth/Enclosure/Patient Leakages(Enclosure/Patient: tester clip to surface of enclosure or Patient lead )
NORMAL (no fault condition + neutral switch closed)
Earth Leakage: Normal/Reversed Polarity, Earth switch depressed (<500 uA) /
Enclosure Leakage: Normal/Reversed Polarity, Chassis switch depressed(<100uA) /
Patient Leakage: Normal/Reversed Polarity, Chassis switch depressed(<100uA) /
SINGLE FAULT (fault condition/ neutral switch open)
Earth Leakage: Normal/Reversed Polarity, Earth switch depressed(<1000uA) /
Enclosure Leakage: Normal/Reversed Polarity, Chassis switch depressed(<500uA) /
Patient Leakage: Normal/Reversed Polarity, Chassis switch depressed(<500uA) /
ACCEPTANCE:
Initials:
Date:
Technician
QC Inspector
