EA UltraTEV Plus 2 - UTP2 Technical Specification

2388-MANUL-V10.00.00-UTP2 Operating Manual
Page 67 of 74
6. UTP2 Technical Specification
Physical
Size
201 x 76 x 34 mm
Weight
0.44 kg
Enclosure
Self-coloured injection moulded plastic case
Screen
3.5” TFT resistive touchscreen
LED backlight
640 x 480 resolution
Indicators
Charging indicator LED
Controls
LCD resistive touchscreen
Membrane Keypad (4x push-buttons)
Connectors
External Ultrasonic Sensor
External Smart Sensor
3.5 mm stereo headphone socket
Micro USB port
Connector safety class
All connectors are Extra-Low Voltage
Hardware
Headphones
Min. 16 ohms
NFC
Frequency: 13.56 MHz
Maximum Power: +17 dBm
Antenna: Integrated loop
Wi-Fi
Frequency: 2.4 GHz
Maximum Power: +17.3 dBm
Module: TI WL1801-MOD
Antenna: TDK ANT016008LCD2442MA1
TEV
Sensor
Capacitive
Measurement Range
0 – 60 dBmV
Pass band
3 – 80 MHz
Resolution
1 dB
Accuracy
±1 dB
Min. Level for Pulse Count
10 dBmV
