EA UltraTEV Plus 2 - UHFR1 Technical Specification

2388-MANUL-V10.00.00-UTP2 Operating Manual
Page 70 of 74
7. UHFR1 Technical Specification
Physical
Size
81 x 40 x 35 mm
Weight
0.1 kg
Enclosure
Aluminium
Indicators
None
Controls
None
Connectors
1x BNC antenna port
1x LEMO (UltraTEV
®
Plus
2
connection)
Environmental
Operating Temperature
0 – 55 degrees C
Humidity
0 – 90% non-condensing
IP Rating
42 (EN 60529)
Power
Power supply
Powered from UltraTEV
®
Plus
2
Supply voltage
5 V
UHF Measurement - General
Modes
Switchable narrowband/wideband
Resolution
1 dBm
Input impedance
50Ω
UHF Measurement - Narrowband
Measurement range
-85 – +5 dBm
Tuning frequency
47 – 1000 MHz
Bandwidth
8 MHz
Gain setting
-10 – +40 dB
Accuracy
±2 dB (0 dB gain; -50 dBm – 0 dBm input, 25⁰C)
