Getting sta
rted
18
1.
Getting started
p
Install the battery
Always switch the radio off and disconnect the charger before
removing the battery.
1.
To remove the battery, pre
ss the release
button (1), litf it upwards (2), a
nd take the
battery out.
2.
To insert the battery, slide it into its
position so that the catches in the upper
part of the battery fit into the holes in the
radio body (1). Press the bottom part of
the battery into its position, untill it clicks
(2).
17
19
Table of Contents
Default Chapter
4
Quick Guide
4
Table of Contents
7
Contents
7
For Your Safety
10
For All Other Radios Except for RC-3
13
General Information
14
Belt Clip
14
Access Codes
14
Modes of Operation
14
Transmission Barring
15
Network Selection
16
Using Your Radio in Wet and Damp Conditions
16
1 Getting Started
18
Install the Battery
18
Install the Electromagnetic Interference Filters
19
For All Other Radios Except for RC-3
19
Charge the Battery
20
Switch the Radio on and off
20
Lock the Keys (Keyguard)
21
2 Your Radio
22
Idle Mode
23
Call Types
24
Red Key Calls and Status Sending
25
Group Selector and Back Key
26
PTT (Push-To-Talk) Key
27
Duty Key and Fast Menu Key
27
Loudspeaker
28
Light Indicator
28
Volume Keys
29
Accessory Connectors
29
Vibration Alert
29
Display Indicators
30
Notifications
32
3 Using Your Radio
34
Access a Menu Function
34
Menu List
35
Fast Menu
37
Voice Feedback
38
4 Group Calls
39
Basics
39
Folders
39
Home Group
40
Dynamic Talk Groups
41
Start Group Communication
41
Switch Group Calls on and off
41
Select a Folder
42
Select a Talk Group
42
Scanning Settings
43
PTT Key Settings
43
Access the Group List in the Idle Mode
44
Receive a Group Call
44
Respond to a Group Call
45
Voice Override
46
Exit a Menu
46
Mute the Call Temporarily
46
Receive a Broadcast Call
46
Make a Group Call
46
Call the Selected Talk Group
46
Call a Scanned Talk Group
47
Call a Dispatcher (Network Service)
47
Talk Groups (Menu 5)
47
Edit Group Folders
48
View Background Folder
49
Restore Group Settings
49
Group Journal
50
5 Express Calls
51
Make an Express Call
51
Reuse a Number
52
Call an Abbreviated TETRA Number
52
Speed Dialling
52
Receive an Express Call
52
Respond to an Express Call
53
Reject an Express Call
53
6 Phone Calls
54
Make a Phone Call
54
Call an Abbreviated TETRA Number
55
Speed Dialling
55
International Phone Calls (Network Service)
55
Call Transfer
56
In-Call Options
56
Answer a Phone Call
56
Mute the Ringing Tone
56
Reject a Phone Call
56
7 Direct Mode
57
Basics
57
Direct Mode Repeater Mode (Optional)
58
Start Direct Mode Communication
58
Activate Direct Mode
58
Select Channels and Groups
59
Scan the Groups on a Channel
59
Receive a Direct Mode Call
59
Respond to a Direct Mode Call
60
Voice Override
60
Mute the Call Temporarily
60
Make a Direct Mode Call
61
Gateway and Repeater
61
Red Key Calls and Emergency Calls in Direct Mode
62
Direct Mode Status Messages
63
8 Positioning
64
GPS Receiver
64
Positioning Application
65
Position Info
65
Waypoints
66
Position Settings
69
9 Write Text
72
Predictive Text Input
72
Traditional Text Input
73
Tips
73
10 Contacts
74
Save Names and Numbers
74
Search for Names
75
Send and Receive Contacts
76
Send Contacts
76
Receive Contacts
76
Organise the Contacts Directory
77
Add Numbers and Text Items
77
Change the Number Type
77
Change the Default Number
77
Delete Contact Entries
78
Settings for Contacts
78
Speed Dials
78
Caller Groups
79
Terminal Info
79
11 Menu Functions
80
Status Msgs. (Menu 1)
80
Unit Alert Messages
81
Send Status Messages
81
Last Sent Status Message Displayed in Idle Mode
82
Status Message with a Time Stamp
83
Read Status Messages
83
Received and Sent Folders
84
User-Specified Folders
84
Delete Status Messages
85
Status Settings
85
Messaging (Menu 2)
85
Write Text Messages
86
Send Text Messages to Multiple Recipients
87
Read Text Messages
88
Inbox and Sent Items Folders
89
Templates
89
Saved Text Msgs
89
And User-Specified Folders
89
Delete Messages
90
Message Settings
90
Log (Menu 3)
91
Recent Calls Lists
91
Counters and Timers
92
Contacts (Menu 4)
92
Talk Groups (Menu 5)
92
Settings (Menu 6)
92
Profiles
92
Call Settings
93
Anykey Answer
93
Summary after Call
93
Phone Settings
94
Push-To-Talk Setting
94
Duty Key Setting
94
Welcome Note
95
Active Mode
95
Direct Mode Settings
96
Keyguard Settings
96
Communication Settings
96
Enhancement Settings
97
Modem Settings
97
Security Settings
98
Display Settings
98
Time and Date Settings
99
Aliasing
100
Restore Factory Settings
101
Gallery (Menu 7)
101
Organiser (Menu 8)
101
Alarm Clock
101
Calendar
102
To-Do List
103
Notes
103
Calculator
104
Countdown Timer
104
Stopwatch
105
Applications (Menu 9)
105
Launch an Application
106
Other Options Available for an Application
106
Other Options Available for a Folder
107
Downloading an Application
108
Positioning (Menu 10)
109
Web (Menu 11)
109
Call Functions During a Browser Connection
109
Basic Steps for Accessing and Using Services
109
Service Settings
110
Enter the Settings Manually
110
Connect to a Browser Service
111
Browse the Pages of a Service
112
Disconnect from a Service
112
Bookmarks
113
Service Inbox
113
The Cache Memory
114
Browser Security
114
12 Data Communication
116
Call Functions During a Packet Data Connection
116
Install Communication Applications and Modem Drivers
116
Connect Your Radio to a PC
117
13 Battery Information
118
Charging and Discharging
118
Care and Maintenance
119
Important Safety Information
120
Medical Devices
120
Emergency Calls
122
