5. Conceal the hoses correctly. Make sure there is no risk of wear or leakage.
6. Attach the hoses and make sure that they cannot rub against other parts.
7. Make sure that all hoses are connected correctly before you put them in operation.
Note: Use the correct torque setting (30-45 Nm).
Install the wall frame of the touchscreen
Note: This procedure is only applicable to a system with a touchscreen.
This procedure describes how to install the wall frame of the touchscreen in a cut-out in the wall.
Note: It is also possible to install the wall frame to the wall without a cut-out:
■ Install the supplied adapter to the wall with 4 screws.
28 0001
