2. Push the
AUTO
button (1).
ā The hydraulic leveling procedure
starts.
Note: To stop the procedure,
push the stop button (2).
Before the procedure can be
started again, the retract all
jacks button must be pushed.
The circles (3) indicate the hydraulic jacks.
When a circle is grey, it means the jack
is in withdrawn position. When the circle is
yellow, it means the jack is in operation.
When the circle is red, the jack is in
extended position.
In the spirit level (4) you can see a blue
circle (5). When the blue circle is in the
middle of the spirit level, the vehicle is
leveled.
Manual leveling
Caution: Make sure that the handbrake of the vehicle is engaged before you start the
procedure.
Caution: If necessary, use support plates below the footplates of the jacks on the lower
side to compensate large height differences.
40 0001
