E&P HYDRAULICS Level M System - Fill the Tank with Oil; Bleed the System

Fill the tank with oil
1. Do a check on the oil level when the
jacks are fully retracted.
2. Remove the filler cap (1) from the oil
tank.
3. Fill the tank with oil, to 2 centimeters
(0.8 inch) (X) below the edge.
Note: Use ATF Dexron
III or Mercon 5 oil.
4. Install the filler cap (1).
Bleed the system
1. On the touchscreen, push
MANUAL (1).
2. Push and hold the retract all jacks
button (1) until there is pressure on the
system and the pump stops.
1
X
1
1
1 3 2
32 0001
US
