Note: It depends on the type of hydraulic pump if the valves must be adjusted by hand or
with the supplied hex key.
1. Carefully turn the four valves on the
pump clockwise, by hand or with the
supplied hex key, until the valves are
fully open.
2. Remove the protective label on the front
side of the electric motor to see the
coupling.
3. To retract all the jacks, put the supplied
hexagon-bit (1/4" HEX) in the coupling
and turn it counterclockwise with an
auxiliary tool.
0001 45
US
