CV3100 series and MINI series high performance general purpose inverter instruction manual
5-18
Monitoring Code
Description
Communication Address
D-24
Output current during first failure(A)
0D18H
D-25
Output voltage during first failure (V)
0D19H
D-26
Bus voltage during first failure(V)
0D1AH
D-27
IGBT temperature during first failure(℃)
0D1BH
D-28
Soft edition
0D1CH
Fault Code
Fault code
Description
Communication Address
Er00
Over current during accelerating operation
0E00H(High eight )
Er01
Over current during decelerating operation
Er02
Over current during steady state operation
Er03
Over voltage during accelerating operation
Er04
Over voltage during decelerating operation
Er05
Over voltage during steady state operation
Er06
Over voltage during stopping
Er07
Under voltage during running
Er08
Phase failure of power input
Er09
Power IGBT module failure
Er10
Overheat of radiator
Er11
Overload of inverter
Er12
Overload of motor
Er13
Peripheral equipment fault
Er14
RS485 communication fault
Er15
Reserved
Er16
Incorrect current detection
Er17
Fault of communication between keypad and control
panel
Er18
CPU failure
Er19
Overheat of radiator
