Monitoring Parameter
Monitoring Code
Description
Communication Address
D-00
Output frequency (Hz)
0D00H
D-01
Setting frequency (Hz)
0D01H
D-02
Output current (A)
0D02H
D-03
Output voltage (V)
0D03H
D-04
Motor Rev. (RPM/min)
0D04H
D-05
Running linear speed(m/s)
0D05H
D-06
Setting linear speed (m/s)
0D06H
D-07
Bus voltage (V)
0D07H
D-08
Input voltage (V)
0D08H
D-09
PID setting value
0D09H
D-10
PID feedback value
0D0AH
D-11
Analog input AI1(V)
0D0BH
D-12
Analog input AI2(A)
0D0CH
D-13
Pulse input frequency (KHz)
0D0DH
D-14
Input terminal status
0D0EH
D-15
Radiator temperature (℃)
0D0FH
D-16
IGBT temperature (℃)
0D10H
D-17
Current count value
0D11H
D-18
Count value set
0D12H
D-19
First failure record
0D13H
D-20
Second failure record
0D14H
D-21
Third failure record
0D15H
D-22
Output frequency during first failure(Hz)
0D16H
D-23
Frequency setting before first failure(Hz)
0D17H
