86-87050-00 A02 - Page 22
3. Operation
3.3 Operating Modes
Normal mode
This is the standard operating mode, set by default
in the factory.
Under normal condition (Normal AC source
available):
LED (20) is ON.
LEDs (30), (32), (34) are green.
The equipment is protected by the UPS.
ECO mode
The main advantage of the Eco mode (see glossary)
is that it reduces the consumption of electrical
power.
Under normal condition (Normal AC source
available):
LED (20) is ON.
LEDs (33), (34) are green.
The equipment is supplied in ECO mode.
AC out of tolerance
If normal AC source is out of tolerance:
LEDs (20), (21) are ON.
LEDs (30), (32), (34) are green.
The equipment is protected by the UPS.
