Eaton C441 Series User Manual

Ratings
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 3
Ratings
The following ratings apply to the C441Q and C441S.
Table 3. Environmental Ratings of the Module
Table 4. Approvals and Certifications
Table 5. Input Power Supply Requirements
The following ratings apply to the C441QS and C441SS.
Table 6. Environmental Ratings of the Module
Table 7. EMC Requirement
Table 8. Input Power Supply Requirements
Description Rating
Transportation
and Storage
Temperature –40 °C to +85 °C (–40 °F to +185 °F)
Humidity 5–95% noncondensing
Operating Temperature –20 °C to +50 °C (–4 °F to +122 °F)
Humidity 5–95% noncondensing
Altitude Above 2000 m (6600 ft), consult factory
Shock IEC
60068-2-27
15 G any direction for 11 milliseconds
Vibration IEC
60068-206
5–150 Hz, 5 G, 0.7 mm maximum
peak-to-peak
Pollution Degree 3
Electrical/EMC Rating
ESD Immunity (IEC61000-4-2) ±8 kV Air, ±4 kV contact
Radiated Immunity (IEC61000-4-3) 10 V/m 80–1000 MHz, 80% amplitude
modulation @ 1 kHz
Fast Transient (IEC61000-4-4) ±2 kV using direct method
Surge (IEC61000-4-5) ±2 kV line-to-ground
RF Conducted (IEC61000-4-6) 10 V, 0.15–80 MHz
Ingress Protection Code IP20
Radiated and Conducted Emissions EN55011 Class A
Agency Certifications UL
®
508
cUL
®
(CSA® C22.2 No. 14)
CE (Low Voltage Directive)
Description Requirement
Voltage Range 18–30 Vdc
Current Draw (Maximum) 30 mA
Description Rating
Transportation
and Storage
Temperature –40 °C to +80 °C (–40 °F to +176 °F)
Humidity 5–95% noncondensing
Operating Temperature –40 °C to +55 °C (–40 °F to +131 °F)
Humidity 5–95% noncondensing
Altitude Above 2000 m (6600 ft), consult factory
Shock IEC
60068-2-27
15 G any direction for 11 milliseconds
Vibration IEC
60068-206
10–150 Hz, 3 G, 0.3 mm maximum
peak-to-peak
Pollution Degree Pollution III
Polar Draw <30 mA Steady State from 24 Vdc
Dielectric
withstand
Equipment rating volts more than 50 V,
potential volts AC 1000+2*V (max marked
voltage)
Item Rating
Agency Certifications cULus by UL to UL 508, CSA C22.2 No. 14
CE (Low Voltage Directive, EMC Directive)
C-TICK
Radiated and Conducted
Emissions
EN 55011 Class A
Electrical/EMC
ESD Immunity (IEC61000-4-2) ±8 kV Air, ±4 kV contact
Radiated Immunity (IEC61000-4-3) 10 V/m 80–1000 MHz,
80% amplitude modulation at 1 kHz
Fast Transient (IEC61000-4-4) ±2 kV supply and IO
±1 kV communications
Surge (IEC61000-4-5) ±2 kV Line to PE and ±1 kV Line-to-Line
RF Conducted (IEC61000-4-6) 10 V, 0.15–100 MHz
Magnetic Field (IEC61000-4-8) DNA
Voltage Dips (IEC61000-4-11) DNA
Protection Degree (IEC60947-1) IP20
Electrical/EMC Rating
Voltage Range 18–30 Vdc
Current Draw (Maximum) 30 mA

Eaton C441 Series Specifications

General

Series	C441
Category	Controller
Type	Electronic Overload Relay
Voltage	24-240V AC/DC
Mounting	DIN Rail
Phase Sensitivity	3-Phase
Input Voltage	24-240V AC/DC
Number of Outputs	2
Protection Rating	IP20
Reset Type	Manual/Automatic
Trip Class	10
Auxiliary Contacts	1NO+1NC
Communication Protocol	Modbus RTU
Operating Temperature	-20°C to 60°C
Dimensions	Varies by model
