Configuration Using the PROFIBUS Configuration File
16 C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com
C441 Motor Insight Overload Protection Relay
Table 17. C441 Motor Insight Configuration File
Parameter Name Location Notes
Enable Device Parameterization Adapter 0 = Ignore user data,
1 = Download Device Parameters
Com Adapter Outputs ComLoss Behavior Adapter 0 = Fail Safe (outputs disabled),
1 = Hold Last state
CT Multiplier Motor Insight Cat No C441BB, C441CB, C441DB
1-4
Cat No C441BA, C441CA, C441DA
1, 2, 3 (150:5), 4 (300:5), 5 (600:5)
Overload FLA Motor Insight Setting is in Amps x 100
Cat No C441BB, C441CB, C441DB
5–22.5 Amps (CT Multiplier = 4)
6.67–30 Amps (CT Multiplier = 3)
10–45 Amps (CT Multiplier = 2)
20–90 Amps (CT Multiplier =1)
Cat No C441BA, C441CA, C441DA
1–5 Amps (CT Multiplier = 2)
2–9 Amps (CT Multiplier = 1)
60–135 Amps (CT Multiplier = 3)
120–270 Amps (CT Multiplier = 4)
240–540 Amps (CT Multiplier = 5)
Overload Trip Class Motor Insight 5–30
Overload Reset Mode Motor Insight 0 = manual reset mode—default
1 = Apply Motor Fault Reset Delay and Motor Faults Number of Restarts
Over Voltage Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Under Voltage Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Phase Order Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
GND Fault Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Voltage Unbalance Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Current Unbalance Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Under Current Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Phase Loss Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Jam Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
Low kW Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
High kW Trip Enable Motor Insight 1 = Trip Enabled; 0 = Warning only
GND Fault Trip Level Motor Insight Setting in Amps x 100
Cat No C441BB, C441CB, C441DB
3–20 A (CT Multiplier = 1)
1.5–10 (CT Multiplier = 2)
1–6.66 (CT Multiplier = 3)
0.75–5 (CT Multiplier = 4)
Default setting is 10 A
Cat No C441BA, C441CA, C441DA
0.3–2.0 A (CT Multiplier = 1)
0.15–1.0 (CT Multiplier = 2)
9–60 (CT Multiplier = 3)
18–120 (CT Multiplier = 4)
36–240 (CT Multiplier = 5)
Default setting is 1 A
GND Fault Trip Delay Motor Insight 1–60 seconds (30) default

Eaton C441 Series Specifications

General

Series	C441
Category	Controller
Type	Electronic Overload Relay
Voltage	24-240V AC/DC
Mounting	DIN Rail
Phase Sensitivity	3-Phase
Input Voltage	24-240V AC/DC
Number of Outputs	2
Protection Rating	IP20
Reset Type	Manual/Automatic
Trip Class	10
Auxiliary Contacts	1NO+1NC
Communication Protocol	Modbus RTU
Operating Temperature	-20°C to 60°C
Dimensions	Varies by model
