PROFIBUS I/O Parameters

32 C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com

S811+ Soft Starter

Table 25. S811+ Available IO Data for Cyclic Polling

IO Size (in bytes) Tag Description

N/A 0 S811 Soft Starter Base Base Module for the CS811 Soft Starter.

Note: Base module must be loaded into slot 1 of the configuration.

This MUST be the first module listed in the configuration.

Output 1 Com Adapter Outputs 0x01 = Turn on Relay1

0x02 = Turn on Relay2

Input 1 Com Adapter Inputs 0x01 = I0 enabled

0x02 = I1 enabled

0x04 = I2 enabled

0x08 = I3 enabled

Input 1 COM Adapter Status 0x0001 = Adapter Connected

0x0002 = Message Error

0x0004 = Adapter Married

Input 1 MOTOR CONTROL STATUS 0 = Running1

1 = Running2

2 = Permissive

3 = Ramp2

4 = LocalControlStatus

5 = Faulted

6 = Warning

7 = In bypass

Input 6 Active Faults & Warning List Latest 3 Fault/Warning codes

Input 2 Motor Control Faults Bit Fault

0 = Phaseloss

1 = Phase Imbalance

2 = Thermal Pile

3 = Overcurrent

4 = Breaker Fault

5 = GND Fault

6 = Motor Stall

7 = Motor Jam

8 = OverTemp

9 = UnderLoad

10 = Reserved

11 = Estop

12 = Reserved

13 = Reserved

14 = Reserved

15 = Other

Input 2 Motor Control Warnings Bit Warning
