PROFIBUS I/O Parameters
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 33
Input 2 Ave 3phase RMS AC Current
as a %of FLA
0–255%; Percent of FLA setting
Input 2 Thermal Pile Percentage 0–255%; Thermal Pile % used (100% trip)
Input 6 Three-Phase RMS AC Voltage L1, L2 & L3 RMS Voltages
Input 4 Total Number of Motor Starts # of motor starts
LSB1, LSB0
MSB, LSB2
Input 1 Analog Input Percent of Rated Range 0–255%; Analog input status reported as% of selected range
Input 1 Analog Input Value Status Value Description
0x00 = Not Active
0x01 = Under Range
0x02 = Over Range
0x03 = Input Overdrive
0x04 = Input in range
Input 1 Discrete Data Input Bit Description
0 = S811 TB Input#1 status
1 = S811 TB Input#2 status
2 = S811 TB input#3 status
3 = S811 TB Input#4 status
4 = C441 Input#1 status
5 = C441 Input#2 status
6 = C441 Input#3 status
7 = C441 Input#4 status
Input 1 Discrete Data Output Bit Description
0 = S811 form1C relay
1 = S811 formA relay
2 = C441 Q1/Network output0
3 = C441 Q2/Network output1
Input 1 Network Outputs Bit Description
0 = C441—Q1/Network output0
1= C441—Q2/Network output1
Input 20 Fault Queue Last 10 Fault Codes
Input 4 Average RMS AC Current—Line Average RMS Line Current (Float)
Input 4 Three-Phase RMS Current On the line L1 RMS Line Current (Float)
Input 4 Three-Phase RMS Current On the line L2 RMS Line Current (Float)
Input 4 Three-Phase RMS Current On the line L3 RMS Line Current (Float)
Input 2 Scaled Average Three-Phase Currents in
Amps—Line
Scaled Average current in Amps
Input 2 Scaled Three-Phase Currents in amps—
Line
L1 RMS current in Amps
Input 2 Scaled Three-Phase Currents in amps—
Line
L2 RMS current in Amps
Input 2 Scaled Three-Phase Currents in amps—
Line
L3 RMS current in Amps
Input 2 Scaled Average Three-Phase Currents in
deciamps—Line
Scaled Average current in 0.1 Amps
Input 2 Scaled Three-Phase Currents in
deciamps—Line
L1 RMS current in 0.1 Amps
Input 2 Scaled Average Three-Phase Currents in
deciamps—Line
L2 RMS current in 0.1 Amps
Table 25. S811+ Available IO Data for Cyclic Polling, continued
IO Size (in bytes) Tag Description
