Overview
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 1
Overview
The C441 PROFIBUS communication adapter is a DPV0
slave device used to connect the C441 Motor Insight
®
and
C440 protective relay and S611 and S811+ soft starters to a
PROFIBUS network. The C441Q/S PROFIBUS adapter
connects to the side of the Motor Insight and the S611 soft
starter, and allows the user to access setup parameters and
IO data of the Motor Insight and the S611 over a PROFIBUS
network.
The C441QS/SS is a stand-alone PROFIBUS adapter that
connects to the C440, S611 and S811+ via hardwired
connections (DO/DI) and allows the user to access setup
parameters and IO data of the C440, S611 and S811+ over
a PROFIBUS network.
The C441QS/SS can also be used as a 4 digital input, 2 relay
output stand-alone IO module on a PROFIBUS network.
The C441 PROFIBUS communication adapters provide the
user with the ability to:
●
Configure C441 Motor Insight, C440 OL relay, S611 and
S811+ soft starter and stand-alone IO setup parameters
over a PROFIBUS network
●
Create custom IO assemblies based upon their
applications needs
●
Exchange IO between a master and slave over a
PROFIBUS network
●
Read out diagnostic information concerning the health
of the devices connected to the C441 PROFIBUS
interface modules
PROFIBUS Specifications
Table 1. PROFIBUS Specifications
Item Specification
PROFIBUS Communications DPV0
Vendor Identification Number 0x019D
PNO Identification Number 0x0C98
Maximum IO Modules 28
Maximum Input Data 100 bytes
Maximum Output Data 20 bytes
Max Diagnostic Message length 21 bytes
Supported PROFIBUS Data rates 9.6 k, 19.2 k, 45.5 k, 93.75 k, 187.5 k,
500 k, 1.5 M, 3 M, 6 M, 12 M
Optional Features Freeze; Sync; and Fail-safe supported
GSD File 019D0C98.gsd @ www.eaton.com
