Eaton C441 Series - S611 Soft Starter Configuration

Configuration Using the PROFIBUS Configuration File
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 19
S611 Soft Starter
Table 19. S611 Soft Starter Configuration File
Parameter Name Location Notes
Extended User Parameter Data
Enable Device Parameterization Adapter 0 = Ignore user data, 1 = Download Device Parameters
Com Adapter Outputs ComLoss Behavior Adapter 0 = Fail Safe (outputs disabled), 1 = Hold Last state
Overload FLA S611 Motor full load amp rating (in 0.1A)
Overload Trip Class S611 Trip class 5, 10, 20, & 30
Start Method S611 Voltage ramp start
Current limit start
Pump start
Start Time S611 Length of start in 0.1 sec. (5–1800)
Initial Torque S611 Initial starting torque applied to motor at beginning of the start profile. (0–100%)
Stop Time* S611 Length of stop ramp in 0.1 sec. (0–600)
0 sec = disabled
Pump Stop Time* S611 Length of pump stop ramp in 0.1sec. (50–1200)
Kick Start Time S611 Length of time to apply kick torque in 0.1 sec. (0–20)
Setting time to 0sec disables kick torque setting.
Kick Start Torque S611 Kick torque applied to motor at beginning of the start profile. (0–100%). Only
Motor Rated Voltage S611 Nameplate Rated motor voltage. (115–600 V)
Under Voltage Percent S611 Under voltage fault threshold. (% rated motor voltage) (1–99%)
Under Voltage Trip Delay S611 Length of under voltage condition before fault in sec. (0–20)
Over Voltage Percent S611 Over voltage fault threshold. (% rated motor voltage) (101–120%)
Over Voltage Trip Delay S611 Length of over voltage condition before fault in sec. (0–20)
Voltage Imbalance Percent S611 Voltage Imbalance fault threshold. (% rated motor voltage) (1–20%)
Voltage Imbalance Trip Delay S611 Length of voltage imbalance condition before fault in sec. (0–20)
Phase Sequence S611 Incoming voltage phase sequence
ABC
ACB
Reset Mode S611 Fault Reset mode
Manual Reset
Auto Reset
Enable Overload trip S611 0 = disable fault
1 = enable fault
Enable Jam trip S611 0 = disable fault
1 = enable fault
Enable Stall trip S611 0 = disable fault
1 = enable fault
Enable Current Imbalance S611 0 = disable fault
1 = enable fault
Enable Load Disconnect trip S611 0 = disable fault
1 = enable fault
Enable Phase Loss trip S611 0 = disable fault
1 = enable fault
Enable Under Voltage trip S611 0 = disable fault
1 = enable fault
Enable Over Voltage trip S611 0 = disable fault
1 = enable fault
Enable Voltage Imbalance trip S611 0 = disable fault
1 = enable fault
