PROFIBUS I/O Parameters
30 C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com
S611 Soft Starter
Table 24. S611 Available IO Data for Cyclic Polling
IO Size (in bytes) Configuration Modules Notes
NA 0 S611 Soft Starter Base Base module for S611 Soft Starter.
Note: Base module must be loaded into slot 1 of the configuration.
This MUST be the first module listed in the configuration.
output 1 Com Adapter Outputs 0x01 = Turn on Relay1
0x02 = Turn on Relay2
input 1 Com Adapter Inputs 0x01 = I0 enabled
0x02 = I1 enabled
0x04 = I2 enabled
0x08 = I3 enabled
input 1 Com Adapter Status 0x0001 = Adapter Connected
0x0002 = Message Error
0x0004 = Adapter Married
0x0008 = Adapter Marriage not complete
input 2 Motor Control Status 0x0001 = Run
0x0004 = In bypass
0x0020 = Faulted
0x0800 = Fault relay enabled
0x1000 = Aux relay enabled
0x2000 = Control from Net
0x4000 = Permissive enabled
input 2 Current I1 Scaling: value in 0.01 Amps
input 2 Current I2 Scaling: value in 0.01 Amps
input 2 Current I3 Scaling: value in 0.01 Amps
input 2 Current Average Scaling: value in 0.01 Amps
input 2 Voltage L1-L2 Line voltage reading
input 2 Voltage L2-L3 Line voltage reading
input 2 Voltage L3-L1 Line voltage reading
input 2 Voltage Average Average 3-phase voltage reading
input 2 Kilowatts Total In 0.1kW
input 2 Power Factor Apparent PF * 100
input 2 Power Sign
input 2 Line frequency Frequency in 0.01 Hz
input 2 Thermal Pile Percentage Thermal pile % used
input 2 Current Unbalance Percent % imbalance
input 2 Voltage Unbalance Percent Percent of measured voltage Imbalance
input 2 Residual Ground Current Measured GND current in 0.1A
input 2 Pole Temperature T1 In 0.1 deg C
input 2 Pole Temperature T2 In 0.1 deg C
input 2 Pole Temperature T3 In 0.1 deg C
input 2 Pole Temperature Average In 0.1 deg C
input 2 Number of Starts Reset Though Command Register
input 2 Run Timer Hours, Reset Though Command Register
