Configuration Using the PROFIBUS Configuration File
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 21
S811+ Soft Starter
Table 20. S811+ Soft Starter Configuration File
Parameter Name Location Notes
Enable Device Parameterization Adapter 0 = Ignore user data
1 = Download Device Parameters
Com Adapter Outputs Com Loss Behavior Adapter 0 = Fail Safe (outputs disabled)
1 = Hold Last State
Overload Trip FLA Value scaled in 0.1A S811+ 110–20,000 range
Overload Trip Class Value S811+ Class 5–30
Motor Rated Volts S811+ 115–600 V (Motor nameplate voltage)
Motor Line Frequency Rating S811+ 50.00–60.00 Hz (in 0.01 Hz)
Motor Wiring Configuration S811+ 0 = Inline Wiring
1 = Inside Delta
Motor Phase Sequence S811+ 0 = ABC Phase sequence
1 = ACB Phase sequence
Motor Start Method S811+ 0 = Voltage Ramp
1 = Current Limit
2 = Unavailable
3 = Pump Start (w pump option)
Percent Initial Torque S811+ 0–100%
Motor Start Ramp Time S811+ 0.5–180 s (in 0.1 sec)
Motor Stop Ramp Time S811+ 0.0–60.0 s (in 0.1 sec)
Motor Pump Stop Time S811+ 20.0–120.0 (in 0.1 sec)
Kick Start Initial Torque S811+ 0–100%
Kick Start Time S811+ 0.0–2.0 sec (in 0.1 sec)
Ramp2 Motor Phase Sequence S811+ 0 = ABC Phase sequence
1 = ACB Phase sequence
Ramp2 Motor Start Method S811+ 0 = Voltage Ramp
1 = Current Limit
2 = Unavailable
3 = Pump Start (w pump option)
Ramp2 Motor Percent Initial Torque S811+ 0–100%
Ramp2 Motor Start Ramp Time S811+ 0.5–180 s (in 0.1 sec)
Ramp2 Motor Stop Ramp Time S811+ 0.0–60.0 s (in 0.1 sec)
Ramp2 Motor Pump Stop Time S811+ 20.0–120.0 (in 0.1 sec)
Ramp2 Motor Kick Start Initial Torque S811+ 0–100%
Ramp2 Motor Kick Start Time S811+ 0.0–2.0 sec (in 0.1 sec)
Motor Control Terminal Block Local Control Enable S811+ 1 = local control only enabled
0 = disable (terminal block input selects local/network control)
