PROFIBUS Diagnostic Telegrams
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 43
11 24–31
12 32–39
13 40–47
14 48–55
15 56–63
16 64–71
17 72–79
18 80–87
19 88–95
20 96–103
21 104–111
22 0 Running1 S/S
1 Running2 S/S
2 Permissive S/S
3 Ramp2 S/S
4 LocalControlStatus S/S
5 Faulted F/S
6 Warning S/S
7 In bypass S/S
23 0 Phaseloss F/S
1 Phase Imbalance F/S
2 Thermal Pile F/S
3 Overcurrent F/S
4 Breaker Fault F/S
5 GND Fault F/S
6 Motor Stall F/S
7 Motor Jam F/S
8 OverTemp F/S
9 UnderLoad F/S
10 Reserved
11 Estop F/S
12 Reserved
13 Reserved
14 Reserved
15 Other F/S
Table 30. S811+ Soft Starter Diagnostic Telegram, continued
Byte Bit Description Ext Diag Bit
