Eaton EATS30N - 7 Specifications

Page 12
ATS-00_EN
7. Specifications
Table 1. Model list
Model Operating voltage Current rating Operating frequency
EATS30N 180V to 264V 30A for CE 45Hz to 65Hz
EATS30H 24A for UL
EATS30P 24A for UL
Table 2. Weights and dimensions
Model Dimensions H x W x D (inch/mm) Weight (lb/kg)
EATS30N
1.7 x 17.4 x 15.4 / 43 x 440 x 390 10.6 / 4.8
EATS30H
1.7 x 17.4 x 15.4 / 43 x 440 x 390 10.6 / 4.8
EATS30P
1.7 x 17.4 x 15.4 / 43 x 440 x 390 17 / 7. 7
Table 3. Electrical input connections
Model Input connection
EATS30N - EATS30H
Hardwired
EATS30P
L6-30P
Table 4. Electrical output connections
Model Output connection
EATS30N - EATS30H
Hardwired
EATS30P
L6-30R
Table 5. Environmental and safety
Safety UL (US) (UL 60950) (EATS30H - EATS30P)
CE (EU) (IEC 60950)
PSE (JP)
EMI CISPR22 Class A and FCC Class A
EMS IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
Operating temperature 0 to 35°C (32°F to 95°F) @30A input (EATS30N only)
0 to 40°C (32°F to 104°F) @25.6A input
Storage temperature -15 to 50°C / 5 to 122°F
Relative humidity 5 to 95% RH (no condensing)
Operating altitude 0 to 2000 meters (0 to 6252 ft)
Audible noise <45dBAmeasuredatadistanceof1meterinfrontoftheATSunder
full-load condition
