26 Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09
FFiigguurree 2299.. PPaasssswwoorrdd SSccrreeeenn
The overview screen will appear
PPaasssswwoorrdd SSeeccuurriittyy
The Power Xpert SPD is shipped with factory default user authentication credentials to allow for initial
installation and configuration. However, factory default authentication credentials are often well known, easily
discoverable and present a significant security risk; therefore, the admin user name and admin password
should be changed at installation to increase cybersecurity protection.
• Limit access to the PX-SPD to reduce cybersecurity risk.
• The maximum number of users that can be setup is six.
• User names should be 5 characters in length or more.
• Password expiration is configurable, the default is set to 90 days.
• Up to three users can access the PX-SPD simultaneously.
Admin users assign a role to new users from one of four possible roles under the User Management tab
through the web UI.
TTaabbllee 11.. UUsseerr RRoollee PPrriivviilleeggeess
RRoollee DDeessccrriippttiioonn IIPP AAddddrr MMooddbbuuss TTOO UUsseerr//PPaassss FFaaccttoorryy RReesseett RReebboooott
Admin All privileges R/W R/W R/W R/W R/W
Engineer Product configuration R/W R/W
Operator Read only R R
Power Xpert SPD User Setup

Eaton SPD Series Specifications

General

Type	Surge Protective Device
Voltage Rating	120/240V, 208Y/120V, 480Y/277V
Surge Current Capacity	Up to 200kA
Modes of Protection	L-N, L-G, N-G
Operating Frequency	50/60Hz
Certifications	UL 1449
SPD Type	Type 1, Type 2
Maximum Surge Current	Up to 200kA
Nominal Discharge Current (In)	10kA, 20kA
Short Circuit Current Rating (SCCR)	Up to 200kA
Enclosure Type	NEMA 1
Mounting	Panel Mount
Standards	UL 1449, IEEE C62.41
Diagnostics	Visual Indicators
Remote Monitoring	Optional
Maximum Discharge Current (Imax)	Up to 200kA
