8. DEVICE PROGRAMMING
Programming of device is possible with “GPRS transmitters configurator”
configuration program described in chapter 6. To program the device establish
connection with a device.
Depending on connection mode there are two ways for programming.
8.1. LOCAL PROGRAMING
To program a device locally follow the procedure:
a) Connect PROG joint (on printed circuit) with COM computer port by way of
service wire, defined in option -> RS-232.
b) Connect power supply to terminals +12V and GND. After connection and
detection of programming wire a module shall signal this with LED diodes: a
green one shall flash and red one shall flicker.
c) Launch software and define device options (description is in chapter 6 of this
Manual ). Provide right PIN code for SIM card.
d) Save settings into memory of device. Saving course is displayed in special
window.
e) After saving disconnect power supply and disassembly service wire.
f) Insert SIM card. Connect module wiring pursuant to guidelines from chapter
3. Turn power supply on.
g) The device is ready to transmit data.
8.2. REMOTE PROGRAMMING
Remote programming of device is possible if:
user uses GPRS transmitters configurator and GSM modem connected to PC
user uses OSM.2007 monitoring system receiver.
In first case remote programming is possible on CSD channel and its procedure is
analogous to local programming, remembering that “Modem GSM” shall be selected
from connection options (See chapter 6.3.5.2 – CSD connection).
