2. FUNCTIONAL AND TECHNICAL PARAMETERS
8 Inputs: (NO/NC)
1 (sabotage input)
Outputs:
Sabotage ( OUT1 ) - 1 ( OC )
Additional (NC,NO,C) - 1 (relay)*
Phone input compatible with
DTMF standard
YES
Digital interface: RS232 (RxD, TxD, RTS, CTS lines)
Operation modes:  GPRS transmission only
 SMS transmission only
 GPRS and SMS transmission
Messages: Sending of text messages for defined mobile
phones
Configuration: Remote - via GPRS link
Remote - SMS
Remote - CSD
Locally - from PC with the use of software and
RS-232 link
Security: SMS/GPRS transmission – AES encoding
Sabotage (OUT1) –
OC type
Additional (NC, NO, C)
- relay
Output current:
Max. 1A Max. 100mA
Voltage supply : 18VAC (16-20VAC)
Current consumption
average/max.:
80mA / 300mA @18VAC**
Dimension: 141mm x 73mm x 35mm
Charge current: Max. 220mA
Charge voltage: 13,8V
Used batteries: Acid-leaded 12V
Battery failure voltage
threshold:
11VDC
+12V Output current Max. 200mA
Used GSM/GPRS modems: Siemens MC55i, Siemens MC55, Siemens
MC56, Wavecom Q55, Simcom SIM300C,
Simcom SIM340C
* Device can be equipped in additional OC type output (OUT2)
** Measured with full charged battery
