10.5. PROGRAMMING
After detection of programming wire diodes indicate programming.
LED Diodes
Description
Green Red
Connected
Service wire
Programming
in CSD mode
10.6. FIRMWARE UPDATING
During programming bootlader operating is indicated. If error follows during
updating there is bootloader in device and another programming of device is
possible.
LED Diodes
Description
Green Red
No program in
device
(1/sec)
Software updating
Received firmware
decoding
10 sec
DTMF
ERR
OK
STATUS
DTMF
ERR
OK
STATUS
