UN=un APN user name. Parameter should be obtained from mobile
network operator. If APN user name contain space sign put it
with “” e.g. “my user name”.
PW=pw APN password. Parameter should be obtained from mobile
network operator. If APN password contain space sign put it
with “” e.g. “my password”.
SERVER=server Server address; it can be in form of IP or domain name
address.
PORT=port Server port number.
DNS1=dns1 Specifies primary DNS server address (only needed when
domain name address is used as SERVER address)
DNS2=dns2 Specifies secondary DNS server address (only needed when
domain name address is used as SERVER address)
SMS=phone number Server phone number. When there is GPRS failure, SMS with
events will be sent to this number.
SMSPERIOD=time Defines in minutes time between SMS test messages sending to
the server.
OLD Switch device operating in encoded protocol mode into
operation in old PX device emulation mode.
RLIMIT Removes automatic temporary locks on all inputs
RLIMIT=inputs_mask Removes selected automatic temporary locks. Parameter is
decimal number made from 9-bit word: A9 … A2, A1, where A1
means TAMPER, A2 INPUT 1 and A9 INPUT8.
EXAMPLE:
RLIMIT=7 removes locks on inputs: TAMPER, IN1, IN2
RLIMIT=1 remove lock on input TAMPER
DT=YY/MM/DD,hh:mm:ss
Sets date and time in the transmitter; must be putted in a
specific format (see the table on the left)
Note: DESC, CMD, GETSTATUS, GETPARAM, GETCFG commands require separate
SMS, so one command with only one SMS.
Samples of commands and device reaction:
Parameters setting:
1111
█
APN=general.t-mobile.uk
█
SERVER=89.112.43.78
█
PORT=6670
█
SMS=500445566
█
SMSPERIOD=25
Parameters verification:
Inquiry: 1111
█
GETCFG
Answer: 89.112.43.78:6670,general.t-mobile.uk
██
,
Inquiry: 1111
█
GETPARAM=SMS
Answer:: 500445566
