The data, information and descriptions, and the technology described herein are the exclusive intellectual property of Snap-on Climate Solutions S.r.l. and
constitute industrial secrets. Said information is communicated in strict confidentiality; said information may be used only for the purpose for which it is
communicated; said information may not be divulged, communicated, or revealed to third parties and/or reproduced by any means for any reason whatsoever; said
information is protected under applicable Italian competition and industrial property law.
Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.132 - 09/11/2021
REF.
DESCRIPTION
CODE
1
Purge valve
VLV2205
2
Refrigerant storage bottle 12l
CNT4003
3
Command panel
CRP5234
4
Bottle manometer
MAN3032
5
High pressure manometer
MAN3160
6
Printer frame
PLA2597-01
7
Printer
STM0007
8
Display frame
PLA2604-00
9
Control panel sticker
ADE6797
10
Low pressure manometer
MAN3161
11
Nipple 1/8Ggas - 1/4SAE
RAC5810
12
Electroinc valve 30mm (witj 12v solenoid)
VLV1575
13
Double pipe union
RAC5998
14
Nipple 1/8Ggas - 1/4SAE
RAC5810
15
A/C pressure switch
PRS4175-D
16
Compressor
GRCMP19-A
17
Motherbord
SCH1603
18
Power supply
SCH1292
19
Manifold
DIS7320
20
Double pipe union
RAC5998
21
Check valve
VLV2000
22
Double pipe union
RAC5998
23
Tee 1/4SAE
RAC5865
24
Glazed sticke Cinquecento12
ADE6805
25
Glazed sticke Ecotechnics
ADE6284
26
Front plastic cover (option)
PLA2430-00
27
Front sticker
ADE6763
28
Condenser fan
CND0005
29
Condenser
GRCND04
30
Nut M12
VIT0038
31
Washer 12x36mm
VIT0033
32
Wheel
RUO7070
33
Vacuum pump
PMP3955
34
Double pipe union
RAC5998
35
Nipple 1/8Ggas - 1/4SAE
RAC5810
36
Electroinc valve 30mm (witj 12v solenoid)
VLV1575
