Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.133 - 09/11/2021
REF.
DESCRIPTION
CODE
37
Nipple 1/8Ggas - 1/4SAE
RAC5810
38
Check valve
VLV2000
39
Double pipe union
RAC5998
40
Dryer filter
FLT5005
41
Oil separator (copper)
AKDIS002
42
Evaporator
AKDIS003
43
Rubber wrapper
CRP0103
44
Check valve
VLV2000
45
Safety pressure switch
PRS4325-D
46
Knob blue tap
PLA2211
47
Knob red tap
PLA2212
48
Knob service connection
PLA2210
49
Red arrow sticker
ADE6758
50
Knob service connection
PLA2210
51
Blue arrow sticker
ADE6759
52
Manual valve
RAC5912
53
Manual valve
RAC5912
54
USB port
ELT5032
55
Rear metal cover
CRP5235
56
Used oil container - red cap
GRCNT025
57
Used oil glazed sticker
ADE6559
58
New oil container PAG - blue cap
GRCNT023
59
New oil PAG glazed sticker
ADE6556
60
New oil non refillable container PAG
AEK285-N
61
New oil container plug -blue button
RAC8083
62
Used oil container plug - red button
RAC8080
63
Oil support plate
CRP5122
64
Bolt M6
VIT0013
65
Bottle support plate
CRP5236
66
Load cell 50kg (bottle and oil)
CEL9514-E
67
Load cell spacer
CRP1240S
68
Main switch
ELT3321
69
Bolt M6 (load cell lock)
VIT0022
70
Nut M6
VIT0003
71
Serrated washer
VIT0035
72
Load cell spacer
CRP1240S
