Media Handling
Introduction
This chapter explains how to load and unload media, and install and
remove a pin bar.
Media
Media thicknesses - 5.5 mil (0.14mm), 6 mil (0.15 mm),
8 mil (0.20mm), 10 mil (0.25mm),
12 mil (0.30mm)
Media size, minimum 10”W x 13”L (254mm x 330mm),
Media size, maximum 25.4”W x 36.5”L (645 x 927mm)
Configuration - Prepunched Press Grooves or Edge Register
Figure 3-1 Media Orientation
L = Length
W = Width
MEDIA
To Next Page
